EIPC-P252P-X30
Speed Dome EIPC-P252P-X30
Overview
30X Optical Zoom, Accurate and fast focusing, Smart IR, up to 150 m (492ft) IR distance, Optical glass window with higher light transmittance, IR anti-reflection window to increase the infrared transmittance, Ultra 265,H.265, H.264, MJPEG, Embedded smart algorithm, Triple streams, Customized OSD, ONVIF Conformance, Innovative snow-removing functionality, More effective heat dissipation system, Intelligent temperature control technology, 6 KV surge protection designed for network interface
Features
Specification
| Camera | |
|---|---|
| Sensor | 1/2.8", progressive scan,2.0megapixel, CMOS |
| Lens | 4.5 ~ 135 mm (30x optical zoom) , AF automatic focusing and motorized zoom lens, Digital Zoom:16x |
| Angle of View(H) | Pan Range:360° (endless), Pan Speed:0.1°/s ~ 240°/s Tilt Range: –15° ~ +90° (auto reverse), Tilt Speed:0.1° ~ 160°/s |
| Shutter | 1/6~1/100000 s, Auto/Manual |
| Minimum Illumination | Colour: 0.01 lux (F1.6, AGC ON) 0 lux with IR |
| Day/Night | Automatically Removable IR-cut filter(ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | 150m |
| Defog | Digital Defog |
| WDR | DWDR |
| Lens Mount | - |
| Iris | Auto/Manual; F1.5~F4.0 |
| Motor Zoom/focus | - |
| Pan Range/Speed | 360° (endless) , 0.1°/s ~ 240°/s |
| Tilt Range/Speed | –15° ~ +90° (auto reverse), 0.1° ~ 160°/s |
| Video | |
|---|---|
| Resolution | 2MP (1920x1080) |
| Video Compression | H.264, H.265, MJPEG, Ultra 265 |
| Frame Rate | 2MP (1920×1080): Max. 30 fps |
| HLC | Supported |
| 9:16 Corridor Mode | - |
| BLC | Supported |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 24 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Smart | |
|---|---|
| Behavior Detection | Cross line, Intrusion, Motion detection |
| Intelligent Identification | Audio detection, Cross line, Defocus, Face detection, Intrusion, Motion detection, People counting, Scene change |
| Statistical Analysis | People counting |
| General Function | Access policy, Alarm input, Alarm output, ARP protection, IP address filtering, RSTP authentication, Tampering Alaram, User Authentication, Watermark |
| Storage | |
|---|---|
| Edge Storage | Micro SD, Up to 128GB |
| Network Storage | ANR |
| Networks | |
|---|---|
| Protocols | 802.1x, ARP, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, NTP, PPPoE, RTCP, RTP, RTSP, SMTP, SNMP, SSL, TCP, TLS, UDP, UPnP |
| Compatible | API, ONVIF(Profile S,Profile G) |
| Interface | |
|---|---|
| Audio I/O | 1/1 |
| Alarm I/O | |
| Serial Port | - |
| Network | 10M/100M Base - TX Ethernet |
| Video Outpout | - |
| Gneral | |
|---|---|
| Power | 24 V AC±25%, 24 V DC±25%,PoE (PSE Required), Power consumption: 9 ~ 42W |
| Dimention (L x W x H) | Ø227x359.4 mm (Ø8.9” x 14.2”) |
| Weight | 5.28 kg (11.6lb) |
| Working Environment | -40°C ~ +65°C |
| Ingress Protection | IP66 |
| Reset Button | - |
| Audio | |
|---|---|
| Audio Compression | G.711 |
| Suppression | Supported |
| Sampling Rate | 8 KHZ |
| Built-in Mic | - |
